Allen-Bradley 1756-OF4

✓ In Stock

1756-OF4 Image 1 thumbnail
1756-OF4 Image 2 thumbnail
1756-OF4 Image 3 thumbnail
1756-OF4 Image 4 thumbnail
1756-OF4 Image 5 thumbnail
Manufacturer: Allen Bradley - PLC
Product Type: PLC/Programmable Logic Controller
Part Number: 1756-OF4
Series: ControlLogix
UPC: 10612598171825

Description:

The 1756-OF4 is an Allen-Bradley ControlLogix non-isolated output module. This unit has 4 Current Voltage Outputs.This Module also uses an analog output.


This unit does not ship with terminal blocks. Terminal blocks may be present in photographs for illustrative purposes.


Automation Stop is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with Automation Stop's 1-year warranty.

  Pay

We accept credit cards from all major providers, as well as PayPal.

  Ship

We offer worldwide shipping with UPS and DHL.

  Warranty

We proudly offer a one year Automation Stop warranty on most products.

Rockwell Disclaimer: The product is used surplus. Automation Stop is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Automation Stop is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Automation Stop also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Automation Stop also makes no representations as to your right to install any such firmware on the product. Automation Stop will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

The Allen-Bradley 1756-OF4 is a non-isolated ControlLogix output module. This module has 4 voltage or current outputs available with a current resolution of 15 bits across 21 milliamperes, 650 nanoamperes per bit for a voltage resolution of 16 bits across 10.5 Volts, 320 microvolts per bit. This Allen-Bradley 1756-OF4 ControlLogix Output Module requires a 20 pin Removable Terminal Block (RTB) housing before it can be installed within a compatible chassis. The compatible RTBs include the part numbers 1756-TBNH and 1756-TBSH. It is absolutely critical that the chassis and power supply are securely installed and grounded before undertaking the installation of Removable Terminal Block and this ControlLogix module.

Data formats available for this module are floating-point mode and integer mode. This module can also multicast fault data and standing to an owner-listening controller using the channel data. Its power consumption is 3.7 Watts of backplane power and its overvoltage protection is 24 Volts Direct Current. The module's circuit detection is simply for current output, but the output should be set to greater than 0.1 milliamps. It also features a short-circuit protection with a limit of no more than 21 milliamps. This Allen-Bradley 1756-OF4 ControlLogix Non-Isolated Output Module has a scan time of 12 milliseconds floating-point and 8 milliseconds integer, with a module error of 0.15% of the range for voltage and 0.3% of the range for current. Its settling time may be a smaller amount than 2 milliseconds to 95% of ultimate value with resistive loads. It also features a maximum power dissipation of 3.25 W (4 channel current) and a thermal dissipation of 10.91 BTU/hr.

Technical Specifications

Region of Manufacture* United States
Type PLC Output Module
Manufacturer: Rockwell Automation
Brand: Allen-Bradley
Product Line: ControlLogix
Module Type: Analog Output Module
Outputs: 4 Current-Voltage
Backplane Current (5 Volts): 150 Milliamps
Backplane Current (24 Volts): 120 Milliamps
Removable Terminal Blocks: 1756-TBNH, 1756-TBSH
Power Dissipation (Max): 4.9 Watts at 60 degrees Celsius
Isolation Voltage: 50 Volts Continuous
Enclosure: None
Data Modes: floating-point and integer

*Region of Manufacture may vary

We offer UPS shipping. Including Ground, 2nd Day Air, Next Day Air and Early AM. Some of our products have a short lead time, so please contact us if you need any item faster than the lead time shown. If you need to order an item internationally please contact us prior to checking out so we can get you a shipping quote. We can ship UPS or DHL internationally. We can also ship on your UPS or FedEx account number.
If the item is found to be defective within 30 days of the invoice date, a full refund can be issued. If an item is found to be defective through normal use and wear after 30 days but within the 1 year period, the Automation Stop Warranty dictates the appropriate course of action. After the 30 day period, Automation Stop reserves the right to decide between refund, repair, or replacement with identical product. Because of the high volume of outgoing and incoming shipments on a day to day basis, we unfortunately cannot accept returns on items ordered mistakenly or part numbers ordered incorrectly. If a special exception is approved, a 20% restocking fee will be assessed. If you have any questions please contact us at sales@automationstop.com.

FAQ

Question: Does Automation Stop offer repairs on the 1756-OF4?

Answer: Yes. We offer repairs for the 1756-OF4 and it comes with our 1 Year Automation Stop Warranty.


Question: What type of warranty comes with the Allen Bradley - PLC and 1756-OF4?

Answer: If you buy the 1756-OF4 through Automationstop.com it comes with our 1 Year Warranty and no other warranties.


Question: Can I buy the 1756-OF4 online?

Answer: Yes. Automation Stop sells the 1756-OF4 online and you can check out for the quantity and condition listed available above.


Question: What is the manufacturer for the 1756-OF4?

Answer: The 1756-OF4 is made by Allen Bradley - PLC.


Question: What type of product is the 1756-OF4?

Answer: The 1756-OF4 is part of the ControlLogix series.


Question: What is the Backplane Current (24 Volts): of the Allen Bradley Automation 1756-OF4?

Answer: The 1756-OF4 has a Backplane Current (24 Volts): of 120 Milliamps.


Question: What Backplane Current (5 Volts): does the Allen-Bradley 1756-OF4 have?

Answer: The Allen-Bradley 1756-OF4 has a Backplane Current (5 Volts): of 150 Milliamps.


Question: What Brand: is included with the 1756-OF4?

Answer: The 1756-OF4 has a Allen Bradley (AB) Brand:.


Question: What Data Modes: does the Allen Bradley Automation 1756-OF4 have?

Answer: The 1756-OF4 has a floating-point and integer Data Modes:.


Question: Does the Allen Bradley-Rockwell Automation 1756-OF4 have a Enclosure:?

Answer: None.


Question: What is the Isolation Voltage: of the Allen Bradley/Rockwell Automation 1756-OF4?

Answer: The Allen Bradley/Rockwell Automation 1756-OF4 has a Isolation Voltage: of 50 Volts Continuous.


Question: What Manufacturer: is included with the 1756-OF4?

Answer: The 1756-OF4 has a Rockwell Automation Manufacturer:.


Question: What Module Type: does the 1756-OF4 have?

Answer: The Allen Bradley 1756-OF4 has a Analog Output Module Module Type:.


Question: What is the Outputs: of the Allen Bradley 1756-OF4?

Answer: The Outputs: of the 1756-OF4 is 4 Current-Voltage.


Question: What Power Dissipation (Max): does the 1756-OF4 have?

Answer: The Rockwell Automation 1756-OF4 has a Power Dissipation (Max): of 4.9 Watts at 60 degrees Celsius.


Question: What Product Line: does the 1756-OF4 have?

Answer: The Rockwell Automation 1756-OF4 has a ControlLogix Product Line:.


Question: What Region of Manufacture* does the 1756-OF4 have?

Answer: The 1756-OF4 has a United States Region of Manufacture*.


Question: What Removable Terminal Blocks: does the 1756-OF4 have?

Answer: The Removable Terminal Blocks: of the 1756-OF4 is 1756-TBNH, 1756-TBSH.


Series information for 1756-OF4

For additional information about 1756-OF4 check the data sheet or manual. Also check the manual PDF for all wiring diagrams, compatibility, troubleshooting, specifications, installation instructions, and accessories (such as batteries, terminal blocks, or cables) regarding 1756-OF4.

Revision Part # Also Known As Availability
1756-OF4/A 1756-OF4 Ser A, Series A, Rev A Request a Quote
1756-OF4/B 1756-OF4 Ser B, Series B, Rev B Request a Quote
