Emerson - GE Fanuc IC694ALG390

✓ In Stock

IC694ALG390 Image 1 thumbnail
IC694ALG390 Image 2 thumbnail
IC694ALG390 Image 3 thumbnail
IC694ALG390 Image 4 thumbnail
IC694ALG390 Image 5 thumbnail
IC694ALG390 Image 6 thumbnail
Manufacturer: Emerson - GE Fanuc
Product Type: Automation Product
Part Number: IC694ALG390
Series: RX3i PacSystem
UPC: 799705802391

Description:

The GE Fanuc Emerson IC694ALG390 is an analog voltage output module that can be employed with RX3i PACSystems. This module provides two output channels with a scan time of 5 milliseconds that can convert a discrete signal of 13 bits to an analog signal. The module offers a single programmed output voltage range. The IC694ALG390 weighs approximately 480 grams (1.05 pounds) while shipping.



Automation Stop is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with Automation Stop's 1-year warranty.

  Pay

We accept credit cards from all major providers, as well as PayPal.

  Ship

We offer worldwide shipping with UPS and DHL.

  Warranty

We proudly offer a one year Automation Stop warranty on most products.

Rockwell Disclaimer: The product is used surplus. Automation Stop is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Automation Stop is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Automation Stop also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Automation Stop also makes no representations as to your right to install any such firmware on the product. Automation Stop will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

The GE Fanuc Emerson IC694ALG390 is an analog voltage output module that can be employed with RX3i PACSystems. This module provides two output channels with a scan time of 5 milliseconds that can convert a discrete signal of 13 bits to an analog signal. The module offers a single programmed output voltage range: from -10 volts to +10 volts with a resolution of 2.5 millivolts. This module draws a current of 32 milliamperes at a voltage of +5 volts DC and a current of 120 milliamperes at a voltage of 24 volts DC. The IC694ALG390 has a LED indicator on the front panel to show the power state of this module.

The IC694ALG390 employs optical isolation to provide electrical isolation with the backplane and wires. The module can be easily mounted in an I/O slot of either a 5 or 10-slot baseplate and at any input or output slots of the RX3i system. This module supports a non-condensing relative humidity range from 5 percent to 95 percent and a vibration frequency range from 10 hertz to 500 hertz. The module offers the possibility to the user or the operator to employ an external power supply to power up the module with a voltage range from 18 volts DC to 30 volts DC. This device can operate at an altitude of up to 1000 meters (3300 feet) without deterioration. The IC694ALG390 weighs approximately 480 grams (1.05 pounds) while shipping and operates at 0 degrees to 60 degrees Celsius (32 degrees to 140 degrees Fahrenheit) for industrial applications.

Technical Specifications

Brand GE Automation Fanuc / Emerson Automation
Series PACSystems RX3i
Part Number IC694ALG390
Description Analog voltage output module
Number of channels 2
Load requirement 32 mA at +5 VDC / 120 mA at 24 VDC
D/A resolution 13 bits
Number of output range 1
Output voltage range -10 to +10 volts
Sign bit N/A
Scan time 5 ms
External supply voltage range 18 VDC to 30 VDC
Resolution 2.5 mV (1 LSB = 2.5 mV)
Output load 5 mA (2 K ohms minimum resistance)
Output load capacitance 2000 pico farads, maximum
Offset 1 mV maximum, 0 to 60°C (32° to 140°F)
Weight 480 g (1.05 lb.)
We offer UPS shipping. Including Ground, 2nd Day Air, Next Day Air and Early AM. Some of our products have a short lead time, so please contact us if you need any item faster than the lead time shown. If you need to order an item internationally please contact us prior to checking out so we can get you a shipping quote. We can ship UPS or DHL internationally. We can also ship on your UPS or FedEx account number.
If the item is found to be defective within 30 days of the invoice date, a full refund can be issued. If an item is found to be defective through normal use and wear after 30 days but within the 1 year period, the Automation Stop Warranty dictates the appropriate course of action. After the 30 day period, Automation Stop reserves the right to decide between refund, repair, or replacement with identical product. Because of the high volume of outgoing and incoming shipments on a day to day basis, we unfortunately cannot accept returns on items ordered mistakenly or part numbers ordered incorrectly. If a special exception is approved, a 20% restocking fee will be assessed. If you have any questions please contact us at sales@automationstop.com.

FAQ

Question: Does Automation Stop offer repairs on the IC694ALG390?

Answer: Yes. We offer repairs for the IC694ALG390 and it comes with our 1 Year Automation Stop Warranty.


Question: What type of warranty comes with the Emerson - GE Fanuc and IC694ALG390?

Answer: If you buy the IC694ALG390 through Automationstop.com it comes with our 1 Year Warranty and no other warranties.


Question: Can I buy the IC694ALG390 online?

Answer: Yes. Automation Stop sells the IC694ALG390 online and you can check out for the quantity and condition listed available above.


Question: What is the manufacturer for the IC694ALG390?

Answer: The IC694ALG390 is made by Emerson - GE Fanuc.


Question: What Brand is included with the Rockwell-Automation IC694ALG390?

Answer: The IC694ALG390 has a GE Automation Fanuc / Emerson Automation Brand.


Question: What D/A resolution does the Rockwell Automation IC694ALG390 have?

Answer: The D/A resolution of the Rockwell Automation IC694ALG390 is 13 bits.


Question: What Description does the Allen Bradley-Rockwell Automation IC694ALG390 have?

Answer: The IC694ALG390 has a Analog voltage output module Description.


Question: What is the External supply voltage range of the IC694ALG390?

Answer: The IC694ALG390 has a External supply voltage range of 18 VDC to 30 VDC.


Question: What is the Load requirement of the Rockwell Automation IC694ALG390?

Answer: The IC694ALG390 has a Load requirement of 32 mA at +5 VDC / 120 mA at 24 VDC.


Question: What is the Number of channels of the Rockwell-Automation IC694ALG390?

Answer: The IC694ALG390 has a Number of channels of 2.


Question: What is the Number of output range of the Rockwell-Automation IC694ALG390?

Answer: The Number of output range of the Rockwell-Automation IC694ALG390 is 1.


Question: What is the Offset of the Allen Bradley IC694ALG390?

Answer: The IC694ALG390 has a Offset of 1 mV maximum, 0 to 60°C (32° to 140°F).


Question: What Output load does the IC694ALG390 have?

Answer: The IC694ALG390 has a Output load of 5 mA (2 K ohms minimum resistance).


Question: What is the Output load capacitance of the IC694ALG390?

Answer: The Rockwell-Automation IC694ALG390 has a Output load capacitance of 2000 pico farads, maximum.


Question: What is the Output voltage range of the IC694ALG390?

Answer: The Output voltage range of the Allen Bradley Automation IC694ALG390 is -10 to +10 volts.


Question: What is the part Number of the IC694ALG390?

Answer: The component Number of the Rockwell Automation IC694ALG390 is IC694ALG390.


Question: What is the Resolution of the IC694ALG390?

Answer: The Resolution of the Allen Bradley Automation IC694ALG390 is 2.5 mV (1 LSB = 2.5 mV).


Question: What Scan time does the Allen Bradley-Rockwell Automation IC694ALG390 have?

Answer: The Scan time of the Allen Bradley-Rockwell Automation IC694ALG390 is 5 ms.


Question: What Sign bit is included with the Allen Bradley/Rockwell Automation IC694ALG390?

Answer: The Allen Bradley/Rockwell Automation IC694ALG390 has a N/A Sign bit.


Question: What Weight does the Allen-Bradley IC694ALG390 have?

Answer: The Weight of the Allen-Bradley IC694ALG390 is 480 g (1.05 lb.).


Series information for IC694ALG390

For additional information about IC694ALG390 check the data sheet or manual. Also check the manual PDF for all wiring diagrams, compatibility, troubleshooting, specifications, installation instructions, and accessories (such as batteries, terminal blocks, or cables) regarding IC694ALG390.

Revision Part # Also Known As Availability
IC694ALG390B IC694ALG390 Series B, Rev B Request a Quote
IC694ALG390C IC694ALG390 Series C, Rev C Request a Quote
