Emerson - GE Fanuc IC694MDL250

✓ In Stock

IC694MDL250 | RX3i PacSystem | Emerson - GE Fanuc | Image 1

IC694MDL250 | RX3i PacSystem | Emerson - GE Fanuc | Image 2

IC694MDL250 | RX3i PacSystem | Emerson - GE Fanuc | Image 3

IC694MDL250 | RX3i PacSystem | Emerson - GE Fanuc | Image 4

IC694MDL250 | RX3i PacSystem | Emerson - GE Fanuc | Image 5

IC694MDL250 | RX3i PacSystem | Emerson - GE Fanuc | Image 6

Manufacturer:	Emerson - GE Fanuc
Product Type:	Automation Product
Part Number:	IC694MDL250
Series:	RX3i PacSystem
UPC:	468248046165

Description:

The GE Fanuc Emerson IC694MDL250 is an input module that includes sixteen (16) isolated input points which support a voltage range from zero (0) Volts AC to 132 Volts AC at a frequency range from 47 Hertz to 63 Hertz. The IC694MDL250 inputs are protected by an RC snubber to suppress noise from the power line and they are labeled with green LED indicators to show the on/off status of inputs. The IC694MDL250 weighs approximately 230 grams (0.5 pounds) while shipping.

Automation Stop is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with Automation Stop's 1-year warranty.

Pay

Paypal, Mastercard, VISA, American Express, Discover

We accept credit cards from all major providers, as well as PayPal.

Ship

We offer worldwide shipping with UPS and DHL.

Warranty

We proudly offer a one year Automation Stop warranty on most products.

Rockwell Disclaimer: The product is used surplus. Automation Stop is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Automation Stop is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Automation Stop also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Automation Stop also makes no representations as to your right to install any such firmware on the product. Automation Stop will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

The GE Fanuc Emerson IC694MDL250 is an input module that includes sixteen (16) isolated input points which support a voltage range from 0 Volts AC to 132 Volts AC at a frequency range from 47 Hertz to 63 hHertz. The IC694MDL250 inputs are protected by an RC snubber to suppress noise from the power line and they are labeled with green LED indicators to show the on/off status of inputs. The IC694MDL250 employs the backplane optical isolation offered by optocouplers to provide electrical isolation of 250 Volts between logic and field sides and 250 Volts between groups. The IC694MDL250 can be easily mounted in any input or output slots of the RX3i system. The IC694MDL250 offers an input filtering time range from 20 milliseconds to 2540 milliseconds which can be set and programmed using the application program.

The IC694MDL250 draws a current of 220 milliamperes at a voltage of +5 Volts DC. The IC694MDL250 inputs draw a current of 7 milliamperes per point and can be either powered or employed on different phases of the same AC power supply. The IC694MDL250 has a red/green LED indicator labelled “TB LED” which indicates the state of the terminal block. The IC694MDL250 supports a spring, box, extended spring, or extended box style front terminal block. The IC694MDL250 contains two (2) red bands located on the front side to warn and indicate that is a high-voltage module. The IC694MDL250 weighs approximately 230 grams (0.5 pounds) while shipping and operates at zero (0) to 60 degrees Celsius (32 to 140 degrees Fahrenheit) for industrial applications.

Technical Specifications

Brand	GE Automation Fanuc / Emerson Automation
Series	16 points, 120 volts AC input module for Rx3i PacSystem
Part Number	IC694MDL250
Number of I/O Points	16
Diagnostics	Field side terminal block reported to RX3i CPU
Rated Voltage	120 VAC
Input Voltage Range	0 – 132 VAC (47 to 63 Hertz), 120 VAC nom.
Isolation	250 Volts between field side and logic side 250 Volts between groups
Input Current	7.0 mA per point (typical) at rated voltage
On-State Voltage	70-132 VAC
Off-State Voltage	0 to 20 VAC
On-State Current	5 mA (minimum)
Off-State Current	2.5 mA (maximum)
On Response Time	+0-1 AC cycles for filter times up to 840m, +1-2 AC cycles for filter times of 840 to 1600ms, +2-3 AC cycles for filter times of 1600 to 1920ms, +3-4 AC cycles for filter times of 1920ms or more
Internal Power Consumption	220mA (all inputs on) from 5 Volt bus on backplane
Weight	230 g (0.5 lb)

We offer UPS shipping. Including Ground, 2nd Day Air, Next Day Air and Early AM. Some of our products have a short lead time, so please contact us if you need any item faster than the lead time shown. If you need to order an item internationally please contact us prior to checking out so we can get you a shipping quote. We can ship UPS or DHL internationally. We can also ship on your UPS or FedEx account number.

If the item is found to be defective within 30 days of the invoice date, a full refund can be issued. If an item is found to be defective through normal use and wear after 30 days but within the 1 year period, the Automation Stop Warranty dictates the appropriate course of action. After the 30 day period, Automation Stop reserves the right to decide between refund, repair, or replacement with identical product. Because of the high volume of outgoing and incoming shipments on a day to day basis, we unfortunately cannot accept returns on items ordered mistakenly or part numbers ordered incorrectly. If a special exception is approved, a 20% restocking fee will be assessed. If you have any questions please contact us at sales@automationstop.com.

FAQ

Question: Does Automation Stop offer repairs on the IC694MDL250?

Answer: Yes. We offer repairs for the IC694MDL250 and it comes with our 1 Year Automation Stop Warranty.

Question: What type of warranty comes with the Emerson - GE Fanuc and IC694MDL250?

Answer: If you buy the IC694MDL250 through Automationstop.com it comes with our 1 Year Warranty and no other warranties.

Question: Can I buy the IC694MDL250 online?

Answer: Yes. Automation Stop sells the IC694MDL250 online and you can check out for the quantity and condition listed available above.

Question: What is the manufacturer for the IC694MDL250?

Answer: The IC694MDL250 is made by Emerson - GE Fanuc.

Question: What Brand is included with the IC694MDL250?

Answer: The IC694MDL250 has a GE Automation Fanuc / Emerson Automation Brand.

Question: What is the Diagnostics of the IC694MDL250?

Answer: The IC694MDL250 has a Diagnostics of Field side terminal block reported to RX3i central processing unit (CPU).

Question: What Input Current does the IC694MDL250 have?

Answer: The IC694MDL250 has a Input Current of 7.0 mA per point (typical) at rated voltage.

Question: What is the Input Voltage Range of the Allen Bradley Automation IC694MDL250?

Answer: The Allen Bradley Automation IC694MDL250 has a Input Voltage Range of 0 – 132 voltage alternating current (VAC) (47 to 63 Hertz), 120 voltage alternating current (VAC) nom..

Question: What Internal Power Consumption does the IC694MDL250 have?

Answer: The IC694MDL250 has a Internal Power Consumption of 220mA (all inputs on) from 5 Volt bus on backplane.

Question: What is the Isolation of the IC694MDL250?

Answer: The Isolation of the Allen Bradley IC694MDL250 is 250 Volts between field side and logic side 250 Volts between groups.

Question: What is the Number of input/output Points of the Rockwell Automation IC694MDL250?

Answer: The Rockwell Automation IC694MDL250 has a Number of input/output Points of 16.

Question: What is the Off-State Current of the IC694MDL250?

Answer: The Off-State Current of the Allen Bradley/Rockwell Automation IC694MDL250 is 2.5 mA (maximum).

Question: What is the Off-State Voltage of the IC694MDL250?

Answer: The Off-State Voltage of the Allen Bradley/Rockwell Automation IC694MDL250 is 0 to 20 voltage alternating current (VAC).

Question: What is the On Response Time of the IC694MDL250?

Answer: The On Response Time of the IC694MDL250 is +0-1 alternating current (AC) cycles for filter times up to 840m, +1-2 alternating current (AC) cycles for filter times of 840 to 1600ms, +2-3 alternating current (AC) cycles for filter times of 1600 to 1920ms, +3-4 alternating current (AC) cycles for filter times of 1920ms or more.

Question: What is the On-State Current of the Allen Bradley/Rockwell Automation IC694MDL250?

Answer: The On-State Current of the Allen Bradley/Rockwell Automation IC694MDL250 is 5 mA (minimum).

Question: What On-State Voltage does the Rockwell-Automation IC694MDL250 have?

Answer: The IC694MDL250 has a On-State Voltage of 70-132 VAC (voltage alternating current).

Question: What is the unit Number of the Allen Bradley Automation IC694MDL250?

Answer: The unit Number of the Allen Bradley Automation IC694MDL250 is IC694MDL250.

Question: What is the Rated Voltage of the IC694MDL250?

Answer: The Allen Bradley Automation IC694MDL250 has a Rated Voltage of 120 voltage alternating current (VAC).

Question: What is the Weight of the IC694MDL250?

Answer: The Weight of the Rockwell Automation IC694MDL250 is 230 g (0.5 lb) .

Series information for IC694MDL250

For additional information about IC694MDL250 check the data sheet or manual. Also check the manual PDF for all wiring diagrams, compatibility, troubleshooting, specifications, installation instructions, and accessories (such as batteries, terminal blocks, or cables) regarding IC694MDL250.

Revision Part #	Also Known As	Availability
IC694MDL250-EA	IC694MDL250 Series EA, Rev EA	Request a Quote
