Emerson - GE Fanuc IC695ALG106

✓ In Stock

IC695ALG106 Image 1 thumbnail
IC695ALG106 Image 2 thumbnail
IC695ALG106 Image 3 thumbnail
IC695ALG106 Image 4 thumbnail
IC695ALG106 Image 5 thumbnail
Manufacturer: Emerson - GE Fanuc
Product Type: Automation Product
Part Number: IC695ALG106
Series: RX3i PacSystem
UPC: 638115013709

Description:

The GE Fanuc Emerson IC695ALG106 is an analog voltage/current input module that can be used for Rx3i PACSystems. This module provides six input channels. These inputs can be programmed for either voltage or current input ranges. The IC695ALG106 weighs approximately 180 grams (0.39 pounds) while shipping.



Automation Stop is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with Automation Stop's 1-year warranty.

  Pay

We accept credit cards from all major providers, as well as PayPal.

  Ship

We offer worldwide shipping with UPS and DHL.

  Warranty

We proudly offer a one year Automation Stop warranty on most products.

Rockwell Disclaimer: The product is used surplus. Automation Stop is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Automation Stop is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Automation Stop also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Automation Stop also makes no representations as to your right to install any such firmware on the product. Automation Stop will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

The GE Fanuc Emerson IC695ALG106 is an analog voltage/current input module that can be used for Rx3i PACSystems. This module provides six input channels that are well isolated and can convert an analog signal to a discrete signal with a resolution of 16 bits. These inputs can be programmed for either voltage or current input ranges: from 4 milliamperes to 20 milliamperes, from 0 milliamperes to 20 milliamperes, from -20 milliamperes to 20 milliamperes, from 0 to 10 volts DC, from -10 to 10 volts DC, from -5 to 5 volts DC, from 0 to 5 volts DC or from 1 to 5 volts DC. This module draws a current of 230 milliamperes at a voltage of +5 volts DC and a current of 320 milliamperes at a voltage of 3.3 volts DC. The IC695ALG106 has three LED indicators on the faceplate to show the power state of this module.

This module operates with either version 5.0 or later of the RX3i CPU firmware. The input module has a red/green LED indicator labeled “TB” which indicates the state of the terminal block. The IC695ALG106 supports a spring, box, extended spring, or extended box style front terminal block. This module can be easily mounted in an RX3i backplane. The module provides diagnostics features. The IC695ALG106 offers the possibility to the user or the operator to employ an external isolated power supply with a voltage of 24 volts DC. This input module weighs approximately 180 grams (0.39 pounds) while shipping and operates at 0 to 60 degrees Celsius (32 degrees to 140 degrees Fahrenheit) for industrial applications.

Technical Specifications

Brand GE Automation Fanuc / Emerson Automation
Series PACSystems RX3i
Part Number IC695ALG106
Description Analog isolated voltage/current input module
Number of channels 6
Load requirement 230 mA maximum @ 5.0V / 320 mA maximum @ 3.3V / 500 mA @ 19.2 V to 30 VDC
ADC resolution 16 bit ADC converted to Floating Point or Integer
Number of input range 8
Input current ranges 0 to 20mA, 4 to 20mA, +/- 20mA
Input voltage ranges +/- 10V, 0 to 10V, +/- 5V, 0 to 5V, 1 to 5V
CPU version PACSystems RX3i CPU required. CPU firmware version 5.0 and later
Power dissipation within module 2.97 watts maximum; with 20mA inputs on all 6 channels
Filter options 8Hz, 12Hz, 16Hz, 40Hz, 250Hz, 1000Hz
Overvoltage +/-35 VDC continuous, maximum
Overcurrent +/-35mA continuous, maximum
Weight 180 g (0.39 lb.)
We offer UPS shipping. Including Ground, 2nd Day Air, Next Day Air and Early AM. Some of our products have a short lead time, so please contact us if you need any item faster than the lead time shown. If you need to order an item internationally please contact us prior to checking out so we can get you a shipping quote. We can ship UPS or DHL internationally. We can also ship on your UPS or FedEx account number.
If the item is found to be defective within 30 days of the invoice date, a full refund can be issued. If an item is found to be defective through normal use and wear after 30 days but within the 1 year period, the Automation Stop Warranty dictates the appropriate course of action. After the 30 day period, Automation Stop reserves the right to decide between refund, repair, or replacement with identical product. Because of the high volume of outgoing and incoming shipments on a day to day basis, we unfortunately cannot accept returns on items ordered mistakenly or part numbers ordered incorrectly. If a special exception is approved, a 20% restocking fee will be assessed. If you have any questions please contact us at sales@automationstop.com.

FAQ

Question: Does Automation Stop offer repairs on the IC695ALG106?

Answer: Yes. We offer repairs for the IC695ALG106 and it comes with our 1 Year Automation Stop Warranty.


Question: What type of warranty comes with the Emerson - GE Fanuc and IC695ALG106?

Answer: If you buy the IC695ALG106 through Automationstop.com it comes with our 1 Year Warranty and no other warranties.


Question: Can I buy the IC695ALG106 online?

Answer: Yes. Automation Stop sells the IC695ALG106 online and you can check out for the quantity and condition listed available above.


Question: What is the manufacturer for the IC695ALG106?

Answer: The IC695ALG106 is made by Emerson - GE Fanuc.


Question: What is the ADC resolution of the IC695ALG106?

Answer: The Rockwell-Automation IC695ALG106 has a ADC resolution of 16 bit ADC converted to Floating Point or Integer.


Question: What Brand does the IC695ALG106 have?

Answer: The IC695ALG106 has a GE Automation Fanuc / Emerson Automation Brand.


Question: What is the central processing unit (CPU) version of the IC695ALG106?

Answer: The central processing unit (CPU) version of the IC695ALG106 is PACSystems RX3i central processing unit (CPU) required. central processing unit (CPU) firmware version 5.0 and later.


Question: What Description does the IC695ALG106 have?

Answer: The Allen-Bradley IC695ALG106 has a Analog isolated voltage/current input module Description.


Question: What Filter options does the IC695ALG106 have?

Answer: The IC695ALG106 has a Filter options of 8Hz, 12Hz, 16Hz, 40Hz, 250Hz, 1000Hz.


Question: What Input current ranges does the IC695ALG106 have?

Answer: The Input current ranges of the IC695ALG106 is 0 to 20mA, 4 to 20mA, +/- 20mA.


Question: What Input voltage ranges does the Allen-Bradley IC695ALG106 have?

Answer: The IC695ALG106 has a Input voltage ranges of +/- 10 volts 0 to 10 volts +/- 10 volts 0 to 10 volts 1 to 5V.


Question: What Load requirement does the Allen Bradley/Rockwell Automation IC695ALG106 have?

Answer: The Load requirement of the Allen Bradley/Rockwell Automation IC695ALG106 is 230 mA maximum @ 5.0 volts / 320 mA maximum @ 3.0 volts / 500 mA @ 19.2 V to 30 VDC.


Question: What is the Number of channels of the IC695ALG106?

Answer: The Allen Bradley-Rockwell Automation IC695ALG106 has a Number of channels of 6.


Question: What is the Number of input range of the IC695ALG106?

Answer: The Number of input range of the Allen Bradley Automation IC695ALG106 is 8.


Question: What is the Overcurrent of the IC695ALG106?

Answer: The Allen Bradley-Rockwell Automation IC695ALG106 has a Overcurrent of +/-35mA continuous, maximum.


Question: What Overvoltage does the Allen Bradley Automation IC695ALG106 have?

Answer: The Overvoltage of the Allen Bradley Automation IC695ALG106 is +/-35 VDC continuous, maximum.


Question: What is the unit Number of the IC695ALG106?

Answer: The Allen-Bradley IC695ALG106 has a unit Number of IC695ALG106.


Question: What Power dissipation within module does the Rockwell-Automation IC695ALG106 have?

Answer: The IC695ALG106 has a Power dissipation within module of 2.97 watts maximum; with 20mA inputs on all 6 channels.


Question: What Weight does the Rockwell Automation IC695ALG106 have?

Answer: The Weight of the IC695ALG106 is 180 g (0.39 lb.).


Series information for IC695ALG106

For additional information about IC695ALG106 check the data sheet or manual. Also check the manual PDF for all wiring diagrams, compatibility, troubleshooting, specifications, installation instructions, and accessories (such as batteries, terminal blocks, or cables) regarding IC695ALG106.
