Emerson - GE Fanuc IC695ALG112

✓ In Stock

IC695ALG112 Image 1 thumbnail
IC695ALG112 Image 2 thumbnail
IC695ALG112 Image 3 thumbnail
IC695ALG112 Image 4 thumbnail
IC695ALG112 Image 5 thumbnail
Manufacturer: Emerson - GE Fanuc
Product Type: Automation Product
Part Number: IC695ALG112
Series: RX3i PacSystem
UPC: 695535479515

Description:

The GE Fanuc manufactured IC695ALG112 is a PACSystem RX3i module. This is an analog input module with 12-isolated single-ended input channels. This module accepts voltage inputs ranging +/- 5VDC, 0 to 5VDC, 1-5VDC (unipolar), -10 to +10 VDC (bipolar), +/- 5VDC, 0 to 5VDC, as well as current input signals ranging from 0 to 20 milliamps, 4 to 20 milliamps, and +/-20milliamps. This module has a 16-bit Analog to Digital converter with conversion to Integer type or Floating Point.



Automation Stop is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with Automation Stop's 1-year warranty.

  Pay

We accept credit cards from all major providers, as well as PayPal.

  Ship

We offer worldwide shipping with UPS and DHL.

  Warranty

We proudly offer a one year Automation Stop warranty on most products.

Rockwell Disclaimer: The product is used surplus. Automation Stop is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Automation Stop is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Automation Stop also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Automation Stop also makes no representations as to your right to install any such firmware on the product. Automation Stop will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

The GE Fanuc Emerson IC695ALG112 is an analog voltage/current input module that can be used under the Rx3i PacSystem. This module provides twelve (12) input channels which are well isolated and can convert an analog signal to a digital signal with a resolution of 16 bits. The IC695ALG112 inputs can be programmed for either voltage or current input ranges: from 4 to 20 milliamperes, zero (0) to 20 milliamperes, and -20 to 20 milliamperes; from zero (0) to 10 Volts DC, -10 to +10 Volts DC, -5 to +5 Volts DC, zero (0) to 5 Volts DC, or from 1 Volt DC to 5 Volts DC. This module draws a current of 490 milliamperes at a voltage of +5 Volts DC and a current of 310 milliamperes at a voltage of 3.3 Volts DC. The IC695ALG112 has three (3) LED indicators which are located on the faceplate to show the power state of this module.

The IC695ALG112 has a red/green LED indicator labelled “TB” which indicates the state of the terminal block. The IC695ALG112 supports a spring, box, extended spring, or extended box style front terminal block. The IC695ALG112 can be easily mounted in an RX3i universal backplane. This module provides diagnostics features and offers the user the ability to employ an external isolated power supply with a voltage of 24 Volts DC. The IC695ALG112 weighs approximately 360 grams (0.79 pounds) while shipping and operates at zero (0) to 60 degrees Celsius (32 to 140 degrees Fahrenheit) for industrial applications.

As an analog input module with eight single-ended input channels, the IC695ALG112 is a PACSystem RX3i Programmable Automation Controller (PAC) module. It can accept voltage and current signals such as 0-10 VDC (unipolar), -10 to +10 VDC (bipolar), +/-5VDC, 0 to 5VDC, 1-5VDC, and 4- 20 mA. Analog to digital conversion (ADC) with a 16-bit resolution is built-in to transform data to either floating point or integer format. To include a proper readout in Supervisory Control and Data Acquisition (SCADA), Human-Machine Interface (HMI), Distributed Control Systems (DCS), and for making uses by control algorithms such as Proportional + Integral + Derivative (PID) controller to implement automatic control, this module is typically used to interface instruments that generate the mentioned signals. There is no thermal derating on the IC695ALG112, and it comes with software-configurable filter choices including (8, 12, 16, 40, 250, 1000 )Hertz. These filter settings are used to assist deliver a more consistent reading and reduce swings. In a 32-bit field, conditioned data can be saved as an IEEE 32-bit or 16-bit integer. For a step change, the analog input of the module settles to 0.1 percent of the final value in 1.7 milliseconds. The module's specified input filter has an impact on this step change reaction. Specifically, 127 milliseconds for an 8 Hz filter, 67 milliseconds for a 12 Hz filter, 56 milliseconds for a 16 Hz filter, 21 milliseconds for a 40 Hertz filter, 3.1 milliseconds for a 250 Hz filter, and 0 milliseconds for a 1000 Hertz filter. Filters of 8, 12, 16, 40, 100, or 250 Hertz are available with the IC695ALG112 input module. For the input voltage, the input module's input impedance is less than 500 kiloohms. The module's maximum open circuit detection time is 1 second. The IC695ALG112 input module packs a lot of punch into a small box. The program is totally customizable and does not require the use of an external jumper. The module has a predictive diagnostics tool that performs error checks during startup and operation. Upgrades can be made using flash memory.

Technical Specifications

Brand GE Automation Fanuc / Emerson Automation
Series Analog isolated voltage/current input module for Rx3i PacSystem
Part Number IC695ALG112
Number of Channels 12
Load Requirement 490 mA maximum @ 5.0V / 310 mA maximum @ 3.3V / 500 mA @ 19.2 V to 30 VDC
ADC Resolution 16-bit ADC converted to Floating Point or Integer
Number of Input Range 7
Input Current Ranges 0 to 20mA, 4 to 20mA, +/- 20mA
Input Voltage Ranges +/- 10V, 0 to 10V, +/- 5V, 0 to 5V, 1 to 5V
CPU Version PACSystems RX3i CPU required. CPU firmware version 5.0 and later
Power Dissipation within Module 4.89 Watts maximum with 20mA inputs on all 12 channels
Filter Options 8Hz, 12Hz, 16Hz, 40Hz, 250Hz, 1000Hz
Overvoltage +/-35 VDC continuous, maximum
Overcurrent +/-35mA continuous, maximum
Weight 360 g (0.79 lb)
