Emerson - GE Fanuc IC695ALG708

✓ In Stock

IC695ALG708 Image 1 thumbnail
IC695ALG708 Image 2 thumbnail
IC695ALG708 Image 3 thumbnail
IC695ALG708 Image 4 thumbnail
IC695ALG708 Image 5 thumbnail
Manufacturer: Emerson - GE Fanuc
Product Type: Automation Product
Part Number: IC695ALG708
Series: RX3i PacSystem
UPC: 359274186157

Description:

The IC695ALG708 is a non-isolated analog voltage/current output module that is manufactured by GE Fanuc. The module provides eight configurable voltage or current output channels. The current output channel can be configured to have an output range of 0 or 20 mA or 4 to 20 mA, while the voltage output can be configured to have a range of +/- 10 V or 0 to 10 V. The module requires an external power source of 24 VDC.



Automation Stop is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with Automation Stop's 1-year warranty.

  Pay

We accept credit cards from all major providers, as well as PayPal.

  Ship

We offer worldwide shipping with UPS and DHL.

  Warranty

We proudly offer a one year Automation Stop warranty on most products.

Rockwell Disclaimer: The product is used surplus. Automation Stop is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Automation Stop is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Automation Stop also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Automation Stop also makes no representations as to your right to install any such firmware on the product. Automation Stop will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

The IC695ALG708 is a Non-Isolated Analog Voltage/Current Output module. It is manufactured by GE Fanuc and is part of the Series 90-70 PACSystem RX3i series. The IC695ALG708 provides the operator with 8 configurable voltage or current output channels and can be configured for the following output ranges: Current = 0 to 20 milliamperes, 4 to 20 milliamperes; Voltage = +/- 10 Volts, 0 to 10 Volts. This module is compatible with the box-style IC694TBB032, the extended box-style IC694TBB132, the spring-style IC694TBS032, and the extended spring-style IC694TBS132 terminal blocks. By utilizing extended terminal blocks, the operator can provide extra shroud depth that is needed for shielded wiring. When this module is used with the terminal blocks mentioned previously, they are required to be located in an RX3i Universal Backplane and must have an RX3i CPU with firmware of 3.0 or later.

Specifications for the IC695ALG708 include a backplane power requirement of 375 milliamperes maximum at 3.3 Volts, a power dissipation of 7.25 Watts maximum, and an external power supply voltage range between +19.2 Volts and +30 Volts DC; current required for the IC695ALG708 is 250 milliamperes maximum. This module has an update rate of 8 milliseconds, which is determined by I/O scan time and is application dependent. Calibration is accurate to within 0.15% of full scale at 25 degrees Celsius and within 0.30% of full scale at 60 degrees Celsius. Maximum current output load is 850 Ohms maximum while maximum voltage output load is 2K Ohms minimum. The IC695ALG708 has a field to backplane isolation of 2550 Volts DC for one second.

The IC695ALG708 must be powered by an external power source supplying 24 VDC. This external source must be connected directly to the terminal block of the module and connect be connected by the TB1 connector on the backplane. The module has three indicator lights on its face. The module's ok LED light shows the status of the module. The field status LED shows whether the external power supply is present and is above the minimum level, as well as indicating operators to any faults that may be present. Lastly, the TB LED indicator alerts operators to whether or not a terminal block has been installed in the module and whether it is experiencing any issues or not. Each of these power supplies provides its own resolution. At 10 VDC, the module has a resolution of 15.9 bits, while the resolution from 0 to 10 VDC is 14.9 bits. In the current range of 0 to 20 mA, the resolution is 15.9 bits, and the resolution is 15.6 bits when the current output is in the 4 to 20 mA range. The output data from the module can be configured as floating-point IEEE 32-bit or 16-bit integer in a 32-bit field. The IC695ALG708 has no thermal derating while in voltage mode. With a voltage output, the module has a typical output gain drift of 20 ppm per degree Celsius. With a current output, the module’s output gain drift is 35 ppm per degree Celsius, typically. The module offers no shield terminal, but if one is added, it should be done on the ground bar along the bottom of the backplane.

Technical Specifications

Brand GE Fanuc
Series PACSystems RX3i Series 90-70
Output Range (Current) 0 to 20 milliamperes, 4 to 20 milliamperes
Output Range (Voltage) +/- 10 Volts, 0 to 10 Volts
Backplane Power Requirements 375 milliamperes maximum at 3.3 Volts
Power Dissipation (within Module) 7.25 Watts, max.
Update Rate 8 milliseconds
Output Load Reactance (Current) 10µH, max.
Output Load Reactance (Voltage) 1 µF, max.
Maximum Output Load (Current) 850 Ohms, max.
Maximum Output Load (Voltage) 2K Ohms
Isolation, Field to Backplane 2550 Volts DC for one second
We offer UPS shipping. Including Ground, 2nd Day Air, Next Day Air and Early AM. Some of our products have a short lead time, so please contact us if you need any item faster than the lead time shown. If you need to order an item internationally please contact us prior to checking out so we can get you a shipping quote. We can ship UPS or DHL internationally. We can also ship on your UPS or FedEx account number.
If the item is found to be defective within 30 days of the invoice date, a full refund can be issued. If an item is found to be defective through normal use and wear after 30 days but within the 1 year period, the Automation Stop Warranty dictates the appropriate course of action. After the 30 day period, Automation Stop reserves the right to decide between refund, repair, or replacement with identical product. Because of the high volume of outgoing and incoming shipments on a day to day basis, we unfortunately cannot accept returns on items ordered mistakenly or part numbers ordered incorrectly. If a special exception is approved, a 20% restocking fee will be assessed. If you have any questions please contact us at sales@automationstop.com.

FAQ

Question: Does Automation Stop offer repairs on the IC695ALG708?

Answer: Yes. We offer repairs for the IC695ALG708 and it comes with our 1 Year Automation Stop Warranty.


Question: What type of warranty comes with the Emerson - GE Fanuc and IC695ALG708?

Answer: If you buy the IC695ALG708 through Automationstop.com it comes with our 1 Year Warranty and no other warranties.


Question: Can I buy the IC695ALG708 online?

Answer: Yes. Automation Stop sells the IC695ALG708 online and you can check out for the quantity and condition listed available above.


Question: What is the manufacturer for the IC695ALG708?

Answer: The IC695ALG708 is made by Emerson - GE Fanuc.


Question: What Backplane Power Requirements does the IC695ALG708 have?

Answer: The Backplane Power Requirements of the IC695ALG708 is 375 milliamperes maximum at 3.3 Volts.


Question: What Brand is included with the IC695ALG708?

Answer: The Allen Bradley IC695ALG708 has a GE Fanuc Brand.


Question: What Isolation, Field to Backplane does the Allen Bradley-Rockwell Automation IC695ALG708 have?

Answer: The Allen Bradley-Rockwell Automation IC695ALG708 has a Isolation, Field to Backplane of 2550 Volts DC (direct current) for one second.


Question: What is the Maximum Output Load (Current) of the Rockwell Automation IC695ALG708?

Answer: The IC695ALG708 has a Maximum Output Load (Current) of 850 Ohms, max..


Question: What Maximum Output Load (Voltage) does the IC695ALG708 have?

Answer: The Allen Bradley Automation IC695ALG708 has a Maximum Output Load (Voltage) of 2K Ohms.


Question: What is the Output Load Reactance (Current) of the Allen Bradley Automation IC695ALG708?

Answer: The IC695ALG708 has a Output Load Reactance (Current) of 10µH, max..


Question: What is the Output Load Reactance (Voltage) of the IC695ALG708?

Answer: The Allen Bradley Automation IC695ALG708 has a Output Load Reactance (Voltage) of 1 µF, max..


Question: What Output Range (Current) does the Allen Bradley/Rockwell Automation IC695ALG708 have?

Answer: The Output Range (Current) of the Allen Bradley/Rockwell Automation IC695ALG708 is 0 to 20 milliamperes, 4 to 20 milliamperes.


Question: What Output Range (Voltage) does the IC695ALG708 have?

Answer: The IC695ALG708 has a Output Range (Voltage) of +/- 10 Volts, 0 to 10 Volts.


Question: What is the Power Dissipation (within Module) of the IC695ALG708?

Answer: The Allen Bradley/Rockwell Automation IC695ALG708 has a Power Dissipation (within Module) of 7.25 Watts, max..


Question: What Update Rate does the Allen Bradley Automation IC695ALG708 have?

Answer: The Update Rate of the IC695ALG708 is 8 milliseconds.


Series information for IC695ALG708

For additional information about IC695ALG708 check the data sheet or manual. Also check the manual PDF for all wiring diagrams, compatibility, troubleshooting, specifications, installation instructions, and accessories (such as batteries, terminal blocks, or cables) regarding IC695ALG708.

Revision Part # Also Known As Availability
IC695ALG708-CB IC695ALG708 Series CB, Rev CB Request a Quote
IC695ALG708-FD IC695ALG708 Series FD, Rev FD Request a Quote
