Emerson - GE Fanuc IC693ALG391

✓ In Stock

IC693ALG391 Image 1 thumbnail
IC693ALG391 Image 2 thumbnail
IC693ALG391 Image 3 thumbnail
IC693ALG391 Image 4 thumbnail
IC693ALG391 Image 5 thumbnail
IC693ALG391 Image 6 thumbnail
Manufacturer: Emerson - GE Fanuc
Product Type: Automation Product
Part Number: IC693ALG391
Series: Series 90-30
UPC: 799705792920

Description:

The GE Fanuc Emerson IC693ALG391 is an analog current output module that can be used for the Series 90-30 of Programmable Logic Controllers (PLCs). This module provides two (2) output channels with a scan time of 5 milliseconds, which can convert a digital signal of 12 bits to an analog signal. The IC693ALG391 offers two programmed output current ranges: from either four (4) to 20 milliamperes or from zero (0) to 20 milliamperes. The IC693ALG391 weighs approximately 340 grams (0.75 pounds) while shipping.



Automation Stop is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with Automation Stop's 1-year warranty.

  Pay

We accept credit cards from all major providers, as well as PayPal.

  Ship

We offer worldwide shipping with UPS and DHL.

  Warranty

We proudly offer a one year Automation Stop warranty on most products.

Rockwell Disclaimer: The product is used surplus. Automation Stop is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Automation Stop is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Automation Stop also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Automation Stop also makes no representations as to your right to install any such firmware on the product. Automation Stop will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

The GE Fanuc Emerson IC693ALG391 is an analog current output module that can be used for the Series 90-30 of Programmable Logic Controllers (PLCs). This module provides two output channels with a scan time of 5 milliseconds which can convert a digital signal of 12 bits to an analog current signal. The IC693ALG391 offers two programmed output current ranges: from either four (4) to 20 milliamperes with a resolution of four (4) microamperes or from zero (0) to 20 milliamperes with a resolution of 5 microamperes. This module draws a current rating of 30 milliamperes at a voltage rating of +5 Volts DC and a current rating of 210 milliamperes at a voltage rating of 24 Volts DC. The IC693ALG391 has a LED indicator on the front panel to show the power state of this module.

The IC693ALG391 employs optical isolation to provide an electrical isolation with the backplane and wires. The IC693ALG391 can be easily mounted in an I/O slot of either a five (5) or 10-slot baseplate. This module generates an internal voltage of +24 Volts DC to drive and control the current loop outputs. The IC693ALG391 state can be easily set using the jumper located in the detachable terminal circuit connector. The IC693ALG391 offers the possibility to the user to employ an external power supply to power both the module and the loop current with a voltage rating range from 20 Volts DC to 30 Volts DC. The IC693ALG391 weighs approximately 340 grams (0.75 pounds) while shipping and operates at zero (0) to 60 degrees Celsius (32 to 140 degrees Fahrenheit) for industrial applications.

Technical Specifications

Brand GE Automation / Emerson Automation
Series Analog current output module for Series 90-30 PLCs
Part Number IC693ALG391
Number of Channels 2
Load Requirement 30 mA at +5 VDC / 210 mA at 24 VDC
D/A Resolution 12 bits
Number of Output Range 2
Output Current Ranges 4 mA- 20 mA/0 - 20 mA
Sign bit N/A
Scan Time 5 milliseconds
External Supply Voltage Range 20 to 30 VDC
Resolution 4 to 20 mA / 0 to 20 mA 4μA / 5 μA
User Load 0 to 850 ohms
Output Load Capacitance 2000 pF
Output Load Inductance 1 H
Weight 340 g (0.75 lb)
We offer UPS shipping. Including Ground, 2nd Day Air, Next Day Air and Early AM. Some of our products have a short lead time, so please contact us if you need any item faster than the lead time shown. If you need to order an item internationally please contact us prior to checking out so we can get you a shipping quote. We can ship UPS or DHL internationally. We can also ship on your UPS or FedEx account number.
If the item is found to be defective within 30 days of the invoice date, a full refund can be issued. If an item is found to be defective through normal use and wear after 30 days but within the 1 year period, the Automation Stop Warranty dictates the appropriate course of action. After the 30 day period, Automation Stop reserves the right to decide between refund, repair, or replacement with identical product. Because of the high volume of outgoing and incoming shipments on a day to day basis, we unfortunately cannot accept returns on items ordered mistakenly or part numbers ordered incorrectly. If a special exception is approved, a 20% restocking fee will be assessed. If you have any questions please contact us at sales@automationstop.com.

FAQ

Question: Does Automation Stop offer repairs on the IC693ALG391?

Answer: Yes. We offer repairs for the IC693ALG391 and it comes with our 1 Year Automation Stop Warranty.


Question: What type of warranty comes with the Emerson - GE Fanuc and IC693ALG391?

Answer: If you buy the IC693ALG391 through Automationstop.com it comes with our 1 Year Warranty and no other warranties.


Question: Can I buy the IC693ALG391 online?

Answer: Yes. Automation Stop sells the IC693ALG391 online and you can check out for the quantity and condition listed available above.


Question: What is the manufacturer for the IC693ALG391?

Answer: The IC693ALG391 is made by Emerson - GE Fanuc.


Question: What Brand does the IC693ALG391 have?

Answer: The IC693ALG391 has a GE Automation / Emerson Automation Brand.


Question: What is the D/A Resolution of the IC693ALG391?

Answer: The IC693ALG391 has a D/A Resolution of 12 bits.


Question: What is the External Supply Voltage Range of the IC693ALG391?

Answer: The IC693ALG391 has a External Supply Voltage Range of 20 to 30 VDC.


Question: What Load Requirement does the IC693ALG391 have?

Answer: The Allen Bradley Automation IC693ALG391 has a Load Requirement of 30 mA at +5 VDC / 210 mA at 24 VDC.


Question: What is the Number of Channels of the Rockwell Automation IC693ALG391?

Answer: The Number of Channels of the IC693ALG391 is 2.


Question: What is the Number of Output Range of the IC693ALG391?

Answer: The IC693ALG391 has a Number of Output Range of 2.


Question: What Output Current Ranges does the Rockwell-Automation IC693ALG391 have?

Answer: The Output Current Ranges of the IC693ALG391 is 4 mA- 20 mA/0 - 20 mA.


Question: What Output Load Capacitance does the IC693ALG391 have?

Answer: The Output Load Capacitance of the IC693ALG391 is 2000 pF.


Question: What Output Load Inductance does the IC693ALG391 have?

Answer: The Output Load Inductance of the Allen Bradley/Rockwell Automation IC693ALG391 is 1 H.


Question: What unit Number does the Allen Bradley/Rockwell Automation IC693ALG391 have?

Answer: The part Number of the IC693ALG391 is IC693ALG391.


Question: What is the Resolution 4 to 20 mA / 0 to 20 mA of the IC693ALG391?

Answer: The Resolution 4 to 20 mA / 0 to 20 mA of the IC693ALG391 is 4μA / 5 μA.


Question: What Scan Time does the IC693ALG391 have?

Answer: The IC693ALG391 has a Scan Time of 5 milliseconds.


Question: What Sign bit does the IC693ALG391 have?

Answer: The IC693ALG391 has a N/A Sign bit.


Question: What User Load does the Allen Bradley Automation IC693ALG391 have?

Answer: The Allen Bradley Automation IC693ALG391 has a User Load of 0 to 850 ohms.


Question: What is the Weight of the IC693ALG391?

Answer: The Weight of the Rockwell-Automation IC693ALG391 is 340 g (0.75 lb).


Series information for IC693ALG391

For additional information about IC693ALG391 check the data sheet or manual. Also check the manual PDF for all wiring diagrams, compatibility, troubleshooting, specifications, installation instructions, and accessories (such as batteries, terminal blocks, or cables) regarding IC693ALG391.

Revision Part # Also Known As Availability
IC693ALG391B IC693ALG391 Series B, Rev B Request a Quote
IC693ALG391C IC693ALG391 Series C, Rev C Request a Quote
IC693ALG391E IC693ALG391 Series E, Rev E Request a Quote
IC693ALG391G IC693ALG391 Series G, Rev G Request a Quote
