| Manufacturer: | Emerson - GE Fanuc |
| Product Type: | Automation Product |
| Part Number: | IC200ALG327 |
| Series: | Versamax |
| UPC: | 193021056719 |
Description:
The GE Fanuc Emerson IC200ALG327 is an analog voltage output module. This module provides twelve (12) single-ended channels. These outputs can be employed as either unipolar or bipolar channels in voltage mode. The IC200ALG327 weighs approximately 270 grams (0.59 pounds) while shipping.
Automation Stop is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with Automation Stop's 1-year warranty.
Pay
We accept credit cards from all major providers, as well as PayPal.
Ship
We offer worldwide shipping with UPS and DHL.
Warranty
We proudly offer a one year Automation Stop warranty on most products.
Rockwell Disclaimer: The product is used surplus. Automation Stop is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Automation Stop is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Automation Stop also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Automation Stop also makes no representations as to your right to install any such firmware on the product. Automation Stop will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.
The GE Fanuc Emerson IC200ALG327 is a VersaMax analog voltage output module that can be employed in many industrial applications. This module provides twelve (12) single-ended channels that can convert an analog signal to a digital signal with a resolution of 13 bits. These outputs can be selected as either unipolar channels with a voltage range from 0 volts DC to 10 volts DC or bipolar channels with a voltage range from -10 volts DC to 10 volts DC through selectable jumpers. The module outputs require an external power supply with a voltage from 18 volts DC to 30 volts DC. This device draws a current of 112 milliamperes at a voltage of +5 volts DC. The IC200ALG327 has two green LED indicators on the faceplate to indicate the presence of field and backplane power.
The IC200ALG327 intelligent processing is achieved by either the NIU or the CPU. The device detects and reports field power loss for each channel. This VersaMax module provides an accuracy of ± 0.3 percent at 25 degrees Celsius (77 degrees Fahrenheit ) and ± 0.5 percent maximum of full scale. The IC200ALG327 offers an updated data rate of 15 milliseconds. The unit employs the backplane optical isolation provided by optocouplers to offer electrical isolation of 250 volts AC continuously and 1500 volts AC for one minute between logic and frame ground. The IC200ALG327 weighs approximately 270 grams (0.59 pounds) while shipping and operates at 0 degrees to 60 degrees Celsius (32 degrees to 140 degrees Fahrenheit) for industrial applications.
Technical Specifications
| Brand | GE Automation Fanuc / Emerson Automation |
| Series | VersaMax |
| Part Number | IC200ALG327 |
| Description | Voltage analog output module |
| Number of channels | 12 single-ended outputs |
| Load requirement | 112 mA maximum at 5 VDC |
| Resolution | 13 bits |
| LED indicators | FLD PWR LED, OK LED |
| Number of output voltage ranges | 2 |
| Output voltage ranges | -10.24 to +10.24 VDC (bipolar range) / 0 to +10.24 VDC (unipolar range) |
| External power supply | +18 to +30VDC |
| Analog update rate | 15 milliseconds |
| Operating temperature | 0 to 60 degrees C (32 to 140 degrees F) |
| Weight | 270 g (0.59 lb) |
FAQ
Question: Does Automation Stop offer repairs on the IC200ALG327?
Answer: Yes. We offer repairs for the IC200ALG327 and it comes with our 1 Year Automation Stop Warranty.
Question: What type of warranty comes with the Emerson - GE Fanuc and IC200ALG327?
Answer: If you buy the IC200ALG327 through Automationstop.com it comes with our 1 Year Warranty and no other warranties.
Question: Can I buy the IC200ALG327 online?
Answer: Yes. Automation Stop sells the IC200ALG327 online and you can check out for the quantity and condition listed available above.
Question: What is the manufacturer for the IC200ALG327?
Answer: The IC200ALG327 is made by Emerson - GE Fanuc.
Question: What is the Analog update rate of the IC200ALG327?
Answer: The IC200ALG327 has a Analog update rate of 15 milliseconds.
Question: What Brand is included with the IC200ALG327?
Answer: The Allen Bradley IC200ALG327 has a GE Automation Fanuc / Emerson Automation Brand.
Question: What Description does the IC200ALG327 have?
Answer: The Rockwell-Automation IC200ALG327 has a Voltage analog output module Description.
Question: What is the External power supply unit of the IC200ALG327?
Answer: The External power supply of the IC200ALG327 is +18 to +30VDC.
Question: What LED indicators are included with the Rockwell-Automation IC200ALG327?
Answer: The Rockwell-Automation IC200ALG327 includes FLD PWR LED, OK LED for its LED indicators.
Question: What Load requirement does the IC200ALG327 have?
Answer: The Load requirement of the Rockwell Automation IC200ALG327 is 112 mA maximum at 5 VDC.
Question: What is the Number of channels of the IC200ALG327?
Answer: The Number of channels of the IC200ALG327 is 12 single-ended outputs.
Question: What Number of output voltage ranges does the IC200ALG327 have?
Answer: The Number of output voltage ranges of the Allen-Bradley IC200ALG327 is 2.
Question: What is the Operating temperature of the Rockwell-Automation IC200ALG327?
Answer: The Rockwell-Automation IC200ALG327 has a Operating temperature of 0 to 60 degrees C (32 to 140 degrees F).
Question: What is the Output voltage ranges of the Allen Bradley IC200ALG327?
Answer: The IC200ALG327 has a Output voltage ranges of -10.24 to +10.24 VDC (bipolar range) / 0 to +10.24 VDC (unipolar range).
Question: What is the component Number of the IC200ALG327?
Answer: The Allen Bradley Automation IC200ALG327 has a part Number of IC200ALG327.
Question: What Resolution does the IC200ALG327 have?
Answer: The Rockwell-Automation IC200ALG327 has a Resolution of 13 bits.
Question: What Weight does the IC200ALG327 have?
Answer: The IC200ALG327 has a Weight of 270 g (0.59 lb).
Series information for IC200ALG327
For additional information about IC200ALG327 check the data sheet or manual. Also check the manual PDF for all wiring diagrams, compatibility, troubleshooting, specifications, installation instructions, and accessories (such as batteries, terminal blocks, or cables) regarding IC200ALG327.
| Revision Part # | Also Known As | Availability |
|---|---|---|
| IC200ALG327F | IC200ALG327 Series F, Rev F | Request a Quote |
