Emerson - GE Fanuc IC200CHS003

✓ In Stock

IC200CHS003 Image 1 thumbnail
IC200CHS003 Image 2 thumbnail
IC200CHS003 Image 3 thumbnail
IC200CHS003 Image 4 thumbnail
IC200CHS003 Image 5 thumbnail
Manufacturer: Emerson - GE Fanuc
Product Type: Automation Product
Part Number: IC200CHS003
Series: Versamax
UPC: 990566636044

Description:

The GE Fanuc Emerson IC200CHS003 is a Compact I/O carrier that contains thirty-six (36) IEC connector-style terminals for a single I/O module field wiring. This carrier provides four common power and thirty-two I/O points connections. The IC200CHS003 supports a current of 2 amperes per point and 8 amperes between power and ground connection. This carrier supports a voltage range from 0 volts AC to 264 volts AC. The IC200CHS003 weighs approximately 110 grams (0.24 pounds) while shipping.



Automation Stop is NOT an authorized distributor for this manufacturer and therefore the manufacturer’s warranty does not apply. Product comes with Automation Stop's 1-year warranty.

  Pay

We accept credit cards from all major providers, as well as PayPal.

  Ship

We offer worldwide shipping with UPS and DHL.

  Warranty

We proudly offer a one year Automation Stop warranty on most products.

Rockwell Disclaimer: The product is used surplus. Automation Stop is not an authorized surplus dealer or affiliate for the Manufacturer of this product. The product may have older date codes or be an older series than that available direct from the factory or authorized dealers. Because Automation Stop is not an authorized distributor of this product, the Original Manufacturer’s warranty does not apply. While many Allen-Bradley PLC products will have firmware already installed, DO Supply makes no representation as to whether a PLC product will or will not have firmware and, if it does have firmware, whether the firmware is the revision level that you need for your application. Automation Stop also makes no representations as to your ability or right to download or otherwise obtain firmware for the product from Rockwell, its distributors, or any other source. Automation Stop also makes no representations as to your right to install any such firmware on the product. Automation Stop will not obtain or supply firmware on your behalf. It is your obligation to comply with the terms of any End-User License Agreement or similar document related to obtaining or installing firmware.

The GE Fanuc Emerson IC200CHS003 is a Compact I/O carrier that contains thirty-six IEC connector-style terminals for a single I/O module field wiring. This carrier provides four common power and thirty-two I/O points connections. The carrier can be easily mounted on a vertical DIN rail by leaving an amount of space of 5.08 centimeters (2 inches) below and above the carrier and 2.54 centimeters (1 inch) from all sides for heat dissipation. The IC200CHS003 includes numbers and alphabetic characters keying dials that are employed during the mounting process. This carrier contains male-female connectors to set the backplane connection and a latch hole to secure and fasten the module to this carrier. The IC200CHS003 supports a current of 2 amperes per point and 8 amperes between power and ground connection.

This carrier supports a voltage range from 0 volts AC to 264 volts AC. This VersaMax product includes a cardholder where a printed wiring card can be introduced. The IC200CHS003 can be easily installed on a 7.5 mm x 35 mm DIN rail that should be grounded for EMC protection. The carrier terminals support a single-stranded or solid wire with a cross-section area from 2.1 square millimeters (14 AWG) to 0.36 square millimeters (22 AWG). The carrier terminals support also two wires with a cross-section area of 0.86 square millimeters (18 AWG). The IC200CHS003 wiring process should employ copper wires rated 90 degrees Celsius (194 degrees Fahrenheit). The IC200CHS003 weighs approximately 110 grams (0.24 pounds) while shipping and operates at 0 degrees to 60 degrees Celsius (32 degrees to 140 degrees Fahrenheit) for industrial applications.

Technical Specifications

Brand GE Automation Fanuc / Emerson Automation
Series VersaMax
Part Number IC200CHS003
Description Compact I/O carrier with connector-style terminals
Number of terminals 36
Single-wire connections Supported
Double-wire connections Supported
Wire type Solid or Stranded copper wire
Mounting DIN rail
Module compatibility All I/O module types except : 240VAC Isolated Input Module, 4 Point - ƒ 240VAC Isolated Input Module, 8 Point - ƒ 240VAC Isolated Input (4 Pt) / Relay Output (8 Pt) mixed module
Lifecycle status Active
Field termination type Integrated
Wiring termination style Connector
Orientation on module on base Vertical
Dimensions (W x H x D) 66.8 mm (2.63 in) x 133.4 mm (5.25 in) x 70 mm (2.75 in), not including the height of DIN-rail
Cables IC200CBL1xxx cable
Operating temperature 0°C to 60°C (32°F to 140°F)
Weight 110 g (0.24 lb.)
We offer UPS shipping. Including Ground, 2nd Day Air, Next Day Air and Early AM. Some of our products have a short lead time, so please contact us if you need any item faster than the lead time shown. If you need to order an item internationally please contact us prior to checking out so we can get you a shipping quote. We can ship UPS or DHL internationally. We can also ship on your UPS or FedEx account number.
If the item is found to be defective within 30 days of the invoice date, a full refund can be issued. If an item is found to be defective through normal use and wear after 30 days but within the 1 year period, the Automation Stop Warranty dictates the appropriate course of action. After the 30 day period, Automation Stop reserves the right to decide between refund, repair, or replacement with identical product. Because of the high volume of outgoing and incoming shipments on a day to day basis, we unfortunately cannot accept returns on items ordered mistakenly or part numbers ordered incorrectly. If a special exception is approved, a 20% restocking fee will be assessed. If you have any questions please contact us at sales@automationstop.com.

FAQ

Question: Does Automation Stop offer repairs on the IC200CHS003?

Answer: Yes. We offer repairs for the IC200CHS003 and it comes with our 1 Year Automation Stop Warranty.


Question: What type of warranty comes with the Emerson - GE Fanuc and IC200CHS003?

Answer: If you buy the IC200CHS003 through Automationstop.com it comes with our 1 Year Warranty and no other warranties.


Question: Can I buy the IC200CHS003 online?

Answer: Yes. Automation Stop sells the IC200CHS003 online and you can check out for the quantity and condition listed available above.


Question: What is the manufacturer for the IC200CHS003?

Answer: The IC200CHS003 is made by Emerson - GE Fanuc.


Question: What Brand does the IC200CHS003 have?

Answer: The Allen Bradley Automation IC200CHS003 has a GE Automation Fanuc / Emerson Automation Brand.


Question: What is the Cables of the IC200CHS003?

Answer: The Allen Bradley Automation IC200CHS003 has a Cables of IC200CBL1xxx cable.


Question: What Description does the IC200CHS003 have?

Answer: The Allen Bradley Automation IC200CHS003 has a Compact input/output carrier with connector-style terminals Description.


Question: What is the Dimensions (W x H x D) of the IC200CHS003?

Answer: The IC200CHS003 has a Dimensions (W x H x D) of 66.8 mm (2.63 in) x 133.4 mm (5.25 in) x 70 mm (2.75 in), not including the height of DIN-rail.


Question: What Double-wire connections are included with the IC200CHS003?

Answer: The Allen Bradley Automation IC200CHS003 includes Supported for its Double-wire connections.


Question: What Field termination type does the IC200CHS003 have?

Answer: The IC200CHS003 has a Integrated Field termination type.


Question: What Lifecycle status are included with the Allen Bradley Automation IC200CHS003?

Answer: The Allen Bradley Automation IC200CHS003 includes Active for its Lifecycle status.


Question: What Module compatibility does the Rockwell Automation IC200CHS003 have?

Answer: The IC200CHS003 has a Module compatibility of All input/output module types except : 240VAC Isolated Input Module, 4 Point - ƒ 240VAC Isolated Input Module, 8 Point - ƒ 240VAC Isolated Input (4 Pt) / Relay Output (8 Pt) mixed module.


Question: What Mounting is included with the Rockwell-Automation IC200CHS003?

Answer: The IC200CHS003 has a DIN rail Mounting.


Question: What is the Number of terminals of the Allen Bradley/Rockwell Automation IC200CHS003?

Answer: The Number of terminals of the IC200CHS003 is 36.


Question: What is the Operating temperature of the IC200CHS003?

Answer: The Operating temperature of the IC200CHS003 is 0°C to 60°C (32°F to 140°F).


Question: What Orientation on module on base does the IC200CHS003 have?

Answer: The Allen Bradley Automation IC200CHS003 has a Vertical Orientation on module on base.


Question: What component Number does the IC200CHS003 have?

Answer: The Allen Bradley IC200CHS003 has a part Number of IC200CHS003.


Question: What kind of Single-wire connections does the Rockwell-Automation IC200CHS003 have?

Answer: The IC200CHS003 has Single-wire connections Supported.


Question: What Weight does the Allen-Bradley IC200CHS003 have?

Answer: The Weight of the Allen-Bradley IC200CHS003 is 110 g (0.24 lb.).


Question: What Wire type does the IC200CHS003 have?

Answer: The IC200CHS003 has a Solid or Stranded copper wire Wire type.


Question: What Wiring termination style does the Allen Bradley IC200CHS003 have?

Answer: The Allen Bradley IC200CHS003 has a Connector Wiring termination style.


Series information for IC200CHS003

For additional information about IC200CHS003 check the data sheet or manual. Also check the manual PDF for all wiring diagrams, compatibility, troubleshooting, specifications, installation instructions, and accessories (such as batteries, terminal blocks, or cables) regarding IC200CHS003.

Revision Part # Also Known As Availability
IC200CHS003A IC200CHS003 Series A, Rev A Request a Quote
IC200CHS003B IC200CHS003 Series B, Rev B Request a Quote
IC200CHS003D IC200CHS003 Series D, Rev D Request a Quote
IC200CHS003H IC200CHS003 Series H, Rev H Request a Quote
IC200CHS003K IC200CHS003 Series K, Rev K Request a Quote
IC200CHS003M IC200CHS003 Series M, Rev M Request a Quote
IC200CHS003P IC200CHS003 Series P, Rev P Request a Quote
IC200CHS003Q IC200CHS003 Series Q, Rev Q Request a Quote
