| Fabricante: | Emerson - GE Fanuc |
| tipo de producto: | Automation Product |
| Número de pieza: | IC660BBD024 |
| Serie: | Genius I/O |
| UPC: | 742066422166 |
Descripción:
El IC660BBD024 es un bloque de entrada/salida (E/S) de fuente discreta de 32 puntos con alta densidad inteligente fabricado por GE Fanuc. Los canales individuales de este módulo se pueden personalizar como entrada, salida o salida con retroalimentación. Los canales de entrada tienen una clasificación de voltaje de 24 V CC , mientras que los canales de salida tienen una clasificación de corriente de 0,5 amperios por canal. Este módulo es capaz de realizar diagnósticos sofisticados y es compatible con el protocolo Genius Bus.
Automation Stop NO es un distribuidor autorizado de este fabricante y, por lo tanto, no se aplica la garantía del fabricante. El producto viene con Automation Stop's 1 año de garantía.
Pagar
Aceptamos tarjetas de crédito de los principales proveedores, así como PayPal.
Barco
Ofrecemos envíos a todo el mundo con UPS y DHL.
Garantía
Estamos orgullosos de ofrecer una garantía de parada de automatización de un año en la mayoría de los productos.
Rockwell Descargo de responsabilidad: El producto se utiliza excedente. Automation Stop no es un distribuidor autorizado de excedentes ni un afiliado del fabricante de este producto. El producto puede tener códigos de fecha más antiguos o ser una serie más antigua que la disponible directamente de fábrica o distribuidores autorizados. Porque Automation Stop no es un distribuidor autorizado de este producto, no se aplica la garantía del fabricante original. Si bien muchos productos de PLC de Allen-Bradley ya tienen firmware instalado, DO Supply no garantiza si un producto de PLC tendrá o no firmware y, si tiene firmware, si el firmware tiene el nivel de revisión que necesita para su solicitud. Automation Stop tampoco garantiza su capacidad o derecho para descargar u obtener firmware para el producto de Rockwell, sus distribuidores o cualquier otra fuente. Automation Stop tampoco garantiza su derecho a instalar dicho firmware en el producto. Automation Stop no obtendrá ni suministrará firmware en su nombre. Es su obligación cumplir con los términos de cualquier Acuerdo de licencia de usuario final o documento similar relacionado con la obtención o instalación de firmware.
The IC660BBD024 is a 12/24 Volt DC 32-Circuit Source Block that is manufactured by GE Fanuc Emerson. It is designed to be an intelligent and configurable module to interface the controller to devices that provide and accept a binary signal. The IC660BBD024 operates at a nominal 12 to 24 Volts DC; it is compatible with a wide range of input devices, including both 2-wire and 3-wire electronic proximity switches. Features for the IC660BBD024 include thirty-two configurable I/O circuits, with the inputs and outputs able to be mixed on block, resettable self-protecting circuits, software configurability, and advanced diagnostics. General specifications for the IC660BBD024 include a size of 8.83 x 3.58 x 4.7 inches, or 22.43 x 9.1 x 11.94 centimeters, a weight of 4 pounds (1.8 kilograms), and LED indicators for Unit OK and I/O Enabled. This hardware has a block to block isolation of 850 Volts and a heat dissipation of 11 Watts minimum with 8 inputs and 18 Watts maximum with 32 outputs at .5 Amperes.
Additional specifications include a maximum ripple of 10% at 12/24 Volts and 1% at 5 Volts, a required DC power of 150 milliamperes typical and 300 milliamperes maximum, and a power supply dropout time of 4 milliseconds at 12 Volts and 20 milliseconds at 24 Volts. Input specifications include a typical input impedance of 3.3K Ohms and a typical input processing time of 1.4 milliseconds. Output specifications for the IC660BBD024 include a maximum output current (steady state) of 0.5 Amperes per circuit and a maximum inrush current of 4 Amperes up to 10 milliseconds (once every .5 seconds maximum). Environmental specifications include an operating temperature range between 0 and 60 degrees Celsius and a storage temperature range between -40 and 100 degrees Celsius; humidity is 5% to 95% (non-condensing). This IC660BBD024 Block has a vibration of 5-10 Hertz 0.2” (5.08 millimeters) displacement, 10-200 Hertz at 1G.
The intelligent Block I/O module IC660BBD024 is a GE Fanuc intelligent Block I/O module. This Module is a high-density 32-point Discrete I/O block featuring individually programmable input, output, and output with feedback channels. This component has source wiring, self-protecting circuitry that may be reset, and sophisticated diagnostics.
One of the IC660BBD024 input's properties is compatibility with 12/24VDC as ON-state signal values. The On-state range for 12VDC is 8-12VDC, whereas the 24VDC On-state range is 18-24VDC. It has a 3.3 K Ohm input impedance and 1.4 milliseconds input processing time, which is influenced by the signal filtering settings, which include a wide series of 1-5 milliseconds, 10, 20, 30, 40, 50, 60, 70, 80, 90, or 100 milliseconds. When set as an output, each channel can produce 0.5 amps with a 0.5 milliseconds turn-on delay and can resist a peak inrush current of 4 amps for 10 milliseconds, which may be cycled once every.5 seconds. This I/O block can handle up to 16 Amps. At 4 Amps inrush, each specified output channel has a maximum voltage drop of 2.0 volts and is capable of identifying switch faults.
For communication with a paired device that is equipped with the Genius Bus protocol, the IC660BBD024 supports it. Bus controllers such as the IC66*CBB902 or CBB903 in any variety, or the IC66*CBB900 or CBB901 in 1.3 or later can be utilized. It may also be set up with the help of the IC66*HHM501 Hand-Held Monitor. The IC66*BSM021 Bus Switching Module (BSM) is compatible with the IC660BBD024 block I/O. Also compatible with the IC660BBD024 I/O block are 2-wire and 3-wire proximity switches, as well as relays, contactors, and lights. The front panel's 32 identical I/O points may be readily customized. When a connection is formed with the contact, a matching LED indication is adjacent to the contact lights.
The GE Fanuc IC660BBD024 I/O block has an 850 V block-to-block isolation rating. For 12 to 24 Volts, it has a maximum ripple of 10%, and for 5 Volts, it has a maximum ripple of 1%. At 12 Volts, the IC660BBD024 I/O block has an electricity dropout of 4 milliseconds, while at 24 Volts, it has a dropout of 20 milliseconds. Proper handling of the block should be assured during installation. Because the block has an open casing, it must be maintained in a clean environment free of airborne pollutants. This Module might be placed both horizontally or vertically, with at least 2 inches between consecutive pieces. The IC660BBD024 I/O block's working temperature range varies between 0 and 60 degrees Celsius, with a maximum humidity level of 95 percentages non-condensing humidity.
Technical Specifications
| Marca | GE Fanuc Emerson |
| Tamaño | 8,83 x 3,58 x 4,7 pulgadas (22,43 x 9,1 x 11,94 centímetros) |
| Peso | 4 libras (1.8 kilogramos) |
| LED | Unidad OK, E / S habilitada |
| Aislamiento de bloque a bloque | 850 voltios |
| Ondulación, máx. | 10% (12/24 voltios), 1% (5 voltios) |
| Alimentación de CC requerida | 150 miliamperios (típico), 300 miliamperios (máx.) |
| Impedancia de entrada (típica) | 3.3K ohmios |
| Corriente de salida del bloque (total) | 16 amperios |
| Temperatura de funcionamiento | 0 a 60 grados centígrados |
| Temperatura de almacenamiento | -40 a 100 grados Celsius |
| Humedad | 5% a 95% (sin condensación) |
| Vibración | 5-10 hercios 0,2 "(5,08 milímetros) de desplazamiento, 10-200 hercios a 1G |
Preguntas más frecuentes
Pregunta: ¿Automation Stop ofrece reparaciones en el IC660BBD024?
Respuesta: Si. Ofrecemos reparaciones para el IC660BBD024 y viene con nuestra garantía de parada de automatización de 1 año.
Pregunta: ¿Qué tipo de garantía viene con Emerson - GE Fanuc e IC660BBD024?
Respuesta: Si compra el IC660BBD024 a través de Automationstop.com, viene con nuestra garantía de 1 año y ninguna otra garantía.
Pregunta: ¿Puedo comprar el IC660BBD024 en línea ?
Respuesta: si Automation Stop vende el IC660BBD024 en línea y puede consultar la cantidad y el estado disponibles arriba.
Pregunta: ¿Cuál es el fabricante del IC660BBD024?
Respuesta: El IC660BBD024 está fabricado por Emerson-GE Fanuc .
Question: What is the Block Output Current (total) of the IC660BBD024?
Answer: The IC660BBD024 has a Block Output Current (total) of 16 Amperes.
Question: What is the Block to Block Isolation of the IC660BBD024?
Answer: The Block to Block Isolation of the IC660BBD024 is 850 Volts.
Question: What Brand is included with the Rockwell-Automation IC660BBD024?
Answer: The Rockwell-Automation IC660BBD024 has a GE Fanuc Emerson Brand.
Question: What is the Humidity of the IC660BBD024?
Answer: The Allen Bradley Automation IC660BBD024 has a Humidity of 5% to 95% (non-condensing).
Question: What is the Input Impedance (typical) of the IC660BBD024?
Answer: The IC660BBD024 has a Input Impedance (typical) of 3.3K Ohms.
Question: What kind of LEDs does the Allen Bradley IC660BBD024 have?
Answer: The Allen Bradley IC660BBD024 has LEDs Unit OK, input/output Enabled.
Question: What Operating Temperature does the IC660BBD024 have?
Answer: The Operating Temperature of the IC660BBD024 is 0 to 60 degrees Celsius.
Question: What is the Required direct current (DC) Power of the Rockwell-Automation IC660BBD024?
Answer: The IC660BBD024 has a Required direct current (DC) Power of 150 milliamperes (typical), 300 milliamperes (max.).
Question: What is the Ripple, max. of the Rockwell-Automation IC660BBD024?
Answer: The Ripple, max. of the Rockwell-Automation IC660BBD024 is 10% (12/24 Volts), 1% (5 Volts).
Question: What is the Size of the IC660BBD024?
Answer: The Size of the IC660BBD024 is 8.83 x 3.58 x 4.7 inch (22.43 x 9.1 x 11.94 centimeters).
Question: What Storage Temperature does the Rockwell-Automation IC660BBD024 have?
Answer: The IC660BBD024 has a Storage Temperature of -40 to 100 degrees Celsius.
Question: What Vibration does the IC660BBD024 have?
Answer: The Allen-Bradley IC660BBD024 has a Vibration of 5-10 Hertz 0.2" (5.08 millimeters) displacement, 10-200 Hertz at 1G.
Question: What Weight does the Allen-Bradley IC660BBD024 have?
Answer: The Weight of the Allen-Bradley IC660BBD024 is 4 pounds (1.8 kilograms).
Información de la serie para IC660BBD024
Para obtener información adicional sobre IC660BBD024 consulte la hoja de datos o el manual. También consulte el manual en PDF para ver todos los diagramas de cableado, compatibilidad, resolución de problemas, especificaciones, instrucciones de instalación y accesorios (como baterías, bloques de terminales o cables) relacionados conIC660BBD024.
| Parte de revisión # | También conocido como | Disponibilidad |
|---|---|---|
| IC660BBD024B | IC660BBD024 Series B, Rev B | Solicitar presupuesto |
| IC660BBD024L | IC660BBD024 Series L, Rev L | Solicitar presupuesto |
| IC660BBD024M | IC660BBD024 Series M, Rev M | Solicitar presupuesto |
| IC660BBD024V | IC660BBD024 Series V, Rev V | Solicitar presupuesto |
| IC660BBD024W | IC660BBD024 Series W, Rev W | Solicitar presupuesto |
| IC660BBD024X | IC660BBD024 Series X, Rev X | Solicitar presupuesto |
| IC660BBD024-X1 | IC660BBD024 Series X1, Rev X1 | Solicitar presupuesto |
